Satin Mineral Grey Vinyl Wrap (SMT01)

Depending on the light, TeckWrap Mineral Grey is a grey that shines with golden glow. It’s a wrap of sophistication and elegance. Order now to get noble.

Specifications

• Material: Conformable and reliable Renolit polymeric material
  Suitable for complete car wrapping (or any smooth or curved surface)
• Film Thickness: 0.12 mm

• Film Thickness with Release Liner: 0.28 mm
• Type of Film: Pressure-sensitive high-grade polymeric vinyl film with air-release channels
• Adhesive: Henkel solvent-based acrylic, transparent, ultra-weather-resistant, viscosity 1000–3000 cps, thickness 12 μm dry
  Release Liner: Felix Schoeller Release Liner / 20-104-20-1,9 printed, double-sided PE coated Kraft. One side solventless silicone-coated, air release (ISO 9001, ISO 140001, OHSAS 18001)
• Storing Period: 3 years if stored at +10°С to +20°С, relative humidity 50%, in original package, away from direct sunlight, clean and dry place
  Durability/Warranty: Datasheet (Click the link)
• Post Heating: 65 °C

Mechanical Properties

• Elongation/Break: MD 206.8 / CD 196.4 (ASTM D882-02)
• Tensile Strength: MD 29.5 / CD 24.8 N/mm² – Speed 200 mm/min (ASTM D882-02)
• Dimensional Stability: 2% shrinkage – Oven/10'*70°C (ASTM D1204-02)
• Surface Tension: 34 dynes/cm (ASTM D2578-04a, 24h after production)

Packaging

• Roll Width: 152 cm
• Roll Length: 18 or 23 m

Installation Tips

• Application Temperature: +17°С – +18°С
• Usage Temperature Range: -45°С – +45°С
• Tools Required: Standard squeegee with soft (wet) buffer
• Conformability: Smooth and medium curved surfaces
• Directional: Yes
• Overlap Width: 3–4 mm

Important Note

• Screen images, colors, and finishes are approximate. Always refer to a physical color swatch for accuracy.
• Use rolls from the same production LOT number for a consistent finish. Slight batch-to-batch variation may occur.
• The film may scratch during application or daily use. Scratches are not covered under warranty.
