Satin Gunsmoke Grey Vinyl Wrap (ECH02)

Film construction

• Film type: high-grade polymeric calendered vinyl with air-release channels
• Series: 190 Series
• Film thickness: 121 μm
• Release liner thickness: 180 μm
• Material: conformable polymeric vinyl with a flat matte metallic finish
• Adhesive: Henkel solvent-based acrylic adhesive, transparent, ultra weather resistant, 1000 to 3000 cps viscosity, 12 μm dry thickness

Performance

• Service temperature: -35°C to +35°C
• Release force: 0.1 N/25mm (standard 0.04 to 0.12)
• Initial tack: 1254 g/25mm (standard 800 to 1500)
• Peel strength (180°): 11.17 N/25mm (standard ≥ 7.85)
• Adhesion strength: 70 (standard ≥ 60, no shifting)
• High temperature aging (65°C, 7 days): no adhesive residue
• Low temperature aging (-65°C, 10 days): no adhesive residue

Warranty

• With proper care and a ceramic coating, this matte metallic finish offers up to 3 years of outdoor durability on vertical panels and around 2 year across a full wrap, depending on climate zone.
• It is more delicate than gloss, and parking indoors or under cover extends its life. Heat-removable, with minimal adhesive residue when removed within the recommended period.

• Application temperature +17°C to +23°C
• Tools: soft squeegee with buffer
• Conformability: flat and moderate curves, deep recesses with inlays
• Post-heat: 100°C
• Cure: 24 hrs above 10°C, 48 hrs at room temperature recommended
• Overlap: 4 to 5 mm
• Directional film, check orientation before cutting
• Avoid overstretching during application
• Remove protective cap before install

Care and maintenance

• This is a flat matte metallic finish and it needs more care than a gloss or satin wrap. Outdoor durability is shorter than gloss and satin and depends heavily on climate, washing habits, and whether the vehicle is kept indoors. Parking under cover meaningfully extends the finish.
• Wait 48 hours after installation before the first wash so the adhesive can fully set.
• Hand wash only, using a pH-neutral shampoo (pH 3 to 11) and a clean microfiber mitt. Rinse grit away first, wash gently, then dry with a clean microfiber towel.
• Avoid automatic car washes, brushes, abrasive pads, and high-pressure washers. All of these mark a matte surface.
• Never use waxes, polishes, gloss enhancers, or any product containing solvents or petroleum distillates. These raise the sheen unevenly, dull the matte, and can permanently degrade the film.
• A vinyl-safe, matte-compatible ceramic coating is recommended for added protection and easier cleaning. Standard gloss coatings will change a matte finish, so use a matte-rated product. Aftermarket coatings are applied at the owner's discretion and any coating-related damage is not covered.
• Spot-clean fingerprints, fuel, bird droppings, and tree sap as soon as
  possible. The longer they sit, the more likely they stain.
• Always test any cleaner or coating in a hidden area before treating the whole vehicle.

• All TeckWrap statements, technical information, and recommendations are based on tests believed to be reliable but do not constitute a guarantee or warranty. All products are sold with the understanding that the buyer has independently determined the suitability of products for their purpose.
• TeckWrap products are warranted to be free of defects in material for the period of shelf life. In case of defects, TeckWrap will replace the product or compensate at its sole discretion. This is the exclusive obligation of TeckWrap Inc.
• Warranty does not cover normal wear, transportation, labor, or consequential damages.
• Screen images may vary, refer to physical color swatches. Use same production LOT for color consistency. Scratches during application or daily use are not covered.
