Azure Flame (Gal33-Hd) 비닐 랩

Film construction

• Film type: Advanced polymeric multilayered film with silver coating and air-release channels
• Film thickness: 132 μm
• Liner thickness: 180 μm (plastic high-gloss liner)
• Adhesive: Henkel solvent polyacrylate, transparent, ultra weather-resistant, viscosity 1000–3000 cps, 12 μm dry
• Finish: High-Gloss aluminum metallic, directional
• Roll width: 1.52 m (5 ft)
• Roll length: 18 m (59 ft)

Performance

• Service temperature: -35°C to +35°C
• 180° Peel strength: 9.7 N/25mm (standard ≥7.85)
• Initial tack: 1055 g/25mm (standard 800–1500)
• Release force: 0.1 N/25mm (standard 0.10–0.30)
• Adhesion: 70 (standard ≥60, no shifting)
• Aging tested: -65°C to +65°C, no residue
• Storage shelf life: 2 years at +10°C to +20°C, 50% RH, dry conditions, away from sunlight.

Warranty

• Built for long-term outdoor use, up to 3 years outdoor durability on vertical panels and around 2 years across a full wrap, depending on climate zone. Heat-removable, with minimal adhesive residue when removed within the recommended three years.

• Apply at +17°C to +23°C
• Tools: soft squeegee with buffer, knife, masking tape, heat gun, magnets, gloves, IR thermometer, IR heater
• Directional film. Orient all panels in the same direction for a consistent metallic flake appearance
• Conformability: flat, curved, and recessed surfaces (do not overstretch)
• Post-heat: 100°C flat surfaces, 120°C curves and overlaps
• Cure time: 24 hours above 15°C; 48 hours at room temperature recommended for maximum adhesive activation
• A steam vacuum or an IR heater is recommended for installation
• Remove the protective cap before installing
• Aftercare: pH-neutral products only, avoid hot wax or strong solvents

All TeckWrap statements, technical information, and recommendations are based on tests believed to be reliable but do not constitute a guarantee or warranty. All products are sold with the understanding that the buyer has independently determined the suitability of the products for their purpose.
TeckWrap products are warranted to be free of defects in materials for the shelf life period. In case of defects, TeckWrap will replace the product or compensate at its sole discretion. This is the exclusive obligation of TeckWrap Inc.
Warranty does not cover normal wear, transportation, labor, or consequential damages.
Screen images may vary; refer to physical color swatches. Use the same production LOT for color consistency. Film must be stored without the protective layer to prevent tunneling. Scratches during application or daily use are not covered.
